Custom identity provider solution

The AWS Transfer Family custom identity provider solution is a modular custom identity provider solution that solves for many common authentication and authorization use cases that enterprises have when implementing the service. This solution provides a reusable foundation for implementing custom identity providers with granular per-user session configuration and separates authentication and authorization logic, offering a flexible and easy-to-maintain foundation for various use cases.

With the AWS Transfer Family custom identity provider solution, you can address common enterprise authentication and authorization use cases. This modular solution offers:

• A reusable foundation for implementing custom identity providers

• Granular per-user session configuration

• Separated authentication and authorization logic

Implementation details for the custom identity toolkit

The solution provides a flexible and maintainable base for various use cases. To get started, review the toolkit at https://github.com/aws-samples/toolkit-for-aws-transfer-family, then follow the deployment instructions in the Getting started section.

Note

If you have previously used custom identity provider templates and examples, consider adopting this solution instead. Moving forward, provider-specific modules will standardize on this solution. Ongoing maintenance and feature enhancements will be applied to this solution.

This solution contains standard patterns for implementing a custom provider that accounts for details including logging and where to store the additional session metadata needed for AWS Transfer Family, such as the HomeDirectoryDetails parameter. This solution provides a reusable foundation for implementing custom identity providers with granular per-user session configuration, and decouples the identity provider authentication logic from the reusable logic that builds a configuration that is returned to Transfer Family to complete authentication and establish settings for the session.

The code and supporting resources for this solution are available at https://github.com/aws-samples/toolkit-for-aws-transfer-family.

The toolkit contains the following features:

• An AWS Serverless Application Model template that provisions the required resources. Optionally, deploy and configure Amazon API Gateway to incorporate AWS WAF, as described in the blog post Securing AWS Transfer Family with AWS Web Application Firewall and Amazon API Gateway.

• An Amazon DynamoDB schema to store configuration metadata about identity providers, including user session settings such as HomeDirectoryDetails, Role, and Policy.

• A modular approach that enables you to add new identity providers to the solution in the future, as modules.

• Attribute retrieval: Optionally retrieve IAM role and POSIX Profile (UID and GID) attributes from supported identity providers, including AD, LDAP, and Okta.

• Support for multiple identity providers connected to a single Transfer Family server and multiple Transfer Family servers using the same deployment of the solution.

• Built-in IP allow-list checking such as IP allow lists that can optionally be configured on a per-user or per-identity provider basis.

• Detailed logging with configurable log-level and tracing support to aid in troubleshooting.

Before you begin to deploy the custom identity provider solution, you need to have the following AWS resources.

• An Amazon Virtual Private Cloud (VPC) with private subnets, with internet connectivity through either a NAT gateway or a DynamoDB gateway endpoint.

• Appropriate IAM permissions to perform the following tasks:

  • Deploy the custom-idp.yaml AWS CloudFormation template,

  • Create AWS CodePipeline projects

  • Create AWS CodeBuild projects

  • Create IAM roles and policies

Important

You must deploy the solution to the same AWS account and AWS Region that contains your target Transfer Family servers.

Supported identity providers

The following list contains details for identity providers that are supported for the custom identity provider solution.

Provider	Password flows	Public key flows	Multi-factor	Attribute retrieval	Details
Active Directory and LDAP	Yes	Yes	No	Yes	User verification can be performed as part of public key authentication flow.
Argon2 (local hash)	Yes	No	No	No	Argon2 hashes are stored in the user record for 'local' password based authentication use cases.
Amazon Cognito	Yes	No	Yes*	No	Time-based One-Time Password (TOTP)-based multi-factor authentication only. *SMS-based MFA is not supported.
Entra ID (formerly Azure AD)	Yes	No	No	No
Okta	Yes	Yes	Yes*	Yes	TOTP-based MFA only.
Public key	No	Yes	No	No	Public keys are stored in the user record in DynamoDB.
Secrets Manager	Yes	Yes	No	No
