Scheduled queries sample schema
In this example we will use a sample application mimicking a DevOps scenario monitoring metrics from a large fleet of servers. Users want to alert on anomalous resource usage, create dashboards on aggregate fleet behavior and utilization, and perform sophisticated analysis on recent and historical data to find correlations. The following diagram provides an illustration of the setup where a set of monitored instances emit metrics to Timestream for LiveAnalytics. Another set of concurrent users issues queries for alerts, dashboards, or ad-hoc analysis, where queries and ingestion run in parallel.
![Diagram showing data flow from servers to Timestream database, with users querying for analytics.](/images/timestream/latest/developerguide/images/schedquery_common_schema_example.png)
The application being monitored is modeled as a highly scaled-out service that is deployed in several regions across the globe. Each region is further subdivided into a number of scaling units called cells that have a level of isolation in terms of infrastructure within the region. Each cell is further subdivided into silos, which represent a level of software isolation. Each silo has five microservices that comprise one isolated instance of the service. Each microservice has several servers with different instance types and OS versions, which are deployed across three availability zones. These attributes that identify the servers emitting the metrics are modeled as dimensions in Timestream for LiveAnalytics. In this architecture, we have a hierarchy of dimensions (such as region, cell, silo, and microservice_name) and other dimensions that cut across the hierarchy (such as instance_type and availability_zone).
The application emits a variety of metrics (such as cpu_user and memory_free) and
events (such as task_completed and gc_reclaimed). Each metric or event is associated
with eight dimensions (such as region or cell) that uniquely identify the server
emitting it. Data is written with the 20 metrics stored together in a multi-measure
record with measure name metrics and all the 5 events are stored together in another
multi-measure record with measure name events. The data model, schema, and data
generation can be found in the open-sourced data generator
Multi-measure records
Table Schema
Below is the table schema once the data is ingested using multi-measure records. It is the output of DESCRIBE query. Assuming the data is ingested into a database raw_data and table devops, below is the query.
DESCRIBE "raw_data"."devops"
Column | Type | Timestream for LiveAnalytics attribute type |
---|---|---|
availability_zone | varchar | DIMENSION |
microservice_name | varchar | DIMENSION |
instance_name | varchar | DIMENSION |
process_name | varchar | DIMENSION |
os_version | varchar | DIMENSION |
jdk_version | varchar | DIMENSION |
cell | varchar | DIMENSION |
region | varchar | DIMENSION |
silo | varchar | DIMENSION |
instance_type | varchar | DIMENSION |
measure_name | varchar | MEASURE_NAME |
time | timestamp | TIMESTAMP |
memory_free | double | MULTI |
cpu_steal | double | MULTI |
cpu_iowait | double | MULTI |
cpu_user | double | MULTI |
memory_cached | double | MULTI |
disk_io_reads | double | MULTI |
cpu_hi | double | MULTI |
latency_per_read | double | MULTI |
network_bytes_out | double | MULTI |
cpu_idle | double | MULTI |
disk_free | double | MULTI |
memory_used | double | MULTI |
cpu_system | double | MULTI |
file_descriptors_in_use | double | MULTI |
disk_used | double | MULTI |
cpu_nice | double | MULTI |
disk_io_writes | double | MULTI |
cpu_si | double | MULTI |
latency_per_write | double | MULTI |
network_bytes_in | double | MULTI |
task_end_state | varchar | MULTI |
gc_pause | double | MULTI |
task_completed | bigint | MULTI |
gc_reclaimed | double | MULTI |
Measure Schema
Below is the measure schema returned by the SHOW MEASURES query.
SHOW MEASURES FROM "raw_data"."devops"
measure_name | data_type | Dimensions |
---|---|---|
events | multi | [{"data_type":"varchar","dimension_name":"availability_zone"},{"data_type":"varchar","dimension_name":"microservice_name"},{"data_type":"varchar","dimension_name":"instance_name"},{"data_type":"varchar","dimension_name":"process_name"},{"data_type":"varchar","dimension_name":"jdk_version"},{"data_type":"varchar","dimension_name":"cell"},{"data_type":"varchar","dimension_name":"region"},{"data_type":"varchar","dimension_name":"silo"}] |
metrics | multi | [{"data_type":"varchar","dimension_name":"availability_zone"},{"data_type":"varchar","dimension_name":"microservice_name"},{"data_type":"varchar","dimension_name":"instance_name"},{"data_type":"varchar","dimension_name":"os_version"},{"data_type":"varchar","dimension_name":"cell"},{"data_type":"varchar","dimension_name":"region"},{"data_type":"varchar","dimension_name":"silo"},{"data_type":"varchar","dimension_name":"instance_type"}] |
Example Data
region | Cell | Silo | availability_zone | microservice_name | instance_name | instance_type | os_version | process_name | jdk_version | measure_name | Time | cpu_user | cpu_system | cpu_idle | cpu_steal | cpu_iowait | cpu_nice | cpu_hi | cpu_si | memory_used | memory_cached | disk_io_reads | latency_per_read | disk_io_writes | latency_per_write | disk_used | disk_free | network_bytes_in | network_bytes_out | file_descriptors_in_use | memory_free | task_end_state | gc_pause | task_completed | gc_reclaimed |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
us-east-2 | us-east-2-cell-1 | us-east-2-cell-1-silo-2 | us-east-2-1 | athena | i-zaZswmJk-athena-us-east-2-cell-1-silo-2-00000216.amazonaws.com | m5.8xlarge | AL2012 | metrics | 11/12/2021 12:43 | 62.8 | 0.408 | 34.2 | 0.972 | 0.0877 | 0.103 | 0.567 | 0.844 | 57.6 | 88.9 | 52.6 | 91.9 | 31.7 | 2.25 | 63.5 | 29.2 | 85.3 | 49.8 | 32.3 | 57.6 | ||||||
us-east-2 | us-east-2-cell-1 | us-east-2-cell-1-silo-2 | us-east-2-1 | athena | i-zaZswmJk-athena-us-east-2-cell-1-silo-2-00000216.amazonaws.com | m5.8xlarge | AL2012 | metrics | 11/12/2021 12:41 | 56 | 0.923 | 39.9 | 0.799 | 0.532 | 0.655 | 0.851 | 0.317 | 90.5 | 31.9 | 56.6 | 37.1 | 25 | 93.3 | 52.2 | 33.1 | 7.14 | 53.7 | 65.9 | 20.4 | ||||||
us-east-2 | us-east-2-cell-1 | us-east-2-cell-1-silo-2 | us-east-2-1 | athena | i-zaZswmJk-athena-us-east-2-cell-1-silo-2-00000216.amazonaws.com | m5.8xlarge | AL2012 | metrics | 11/12/2021 12:39 | 48.5 | 0.801 | 48.2 | 0.18 | 0.943 | 0.0316 | 0.844 | 0.54 | 97.4 | 41.4 | 55.1 | 32.7 | 86.2 | 33.7 | 72.7 | 61.5 | 80.8 | 5.15 | 44.3 | 8.5 | ||||||
us-east-2 | us-east-2-cell-1 | us-east-2-cell-1-silo-2 | us-east-2-1 | athena | i-zaZswmJk-athena-us-east-2-cell-1-silo-2-00000216.amazonaws.com | m5.8xlarge | AL2012 | metrics | 11/12/2021 12:38 | 37.5 | 0.723 | 58.8 | 0.317 | 0.608 | 0.859 | 0.791 | 0.393 | 4.84 | 78.9 | 20.3 | 41.4 | 46.8 | 3.87 | 84.6 | 60.6 | 21.1 | 11.8 | 2.76 | 10 | ||||||
us-east-2 | us-east-2-cell-1 | us-east-2-cell-1-silo-2 | us-east-2-1 | athena | i-zaZswmJk-athena-us-east-2-cell-1-silo-2-00000216.amazonaws.com | m5.8xlarge | AL2012 | metrics | 11/12/2021 12:36 | 58 | 0.786 | 38.7 | 0.219 | 0.436 | 0.829 | 0.331 | 0.734 | 51 | 36.8 | 81.8 | 50.5 | 77.9 | 17.8 | 82.3 | 64 | 7.69 | 66.5 | 56.2 | 31.3 | ||||||
us-east-2 | us-east-2-cell-1 | us-east-2-cell-1-silo-2 | us-east-2-1 | athena | i-zaZswmJk-athena-us-east-2-cell-1-silo-2-00000216.amazonaws.com | host_manager | JDK_8 | events | 11/12/2021 12:43 | 75.8 | SUCCESS_WITH_NO_RESULT | 85.5 | 348 | 64.8 | |||||||||||||||||||||
us-east-2 | us-east-2-cell-1 | us-east-2-cell-1-silo-2 | us-east-2-1 | athena | i-zaZswmJk-athena-us-east-2-cell-1-silo-2-00000216.amazonaws.com | host_manager | JDK_8 | events | 11/12/2021 12:41 | 7.47 | SUCCESS_WITH_RESULT | 22.8 | 42 | 7.45 | |||||||||||||||||||||
us-east-2 | us-east-2-cell-1 | us-east-2-cell-1-silo-2 | us-east-2-1 | athena | i-zaZswmJk-athena-us-east-2-cell-1-silo-2-00000216.amazonaws.com | host_manager | JDK_8 | events | 11/12/2021 12:39 | 64.1 | SUCCESS_WITH_RESULT | 6.77 | 249 | 72.3 | |||||||||||||||||||||
us-east-2 | us-east-2-cell-1 | us-east-2-cell-1-silo-2 | us-east-2-1 | athena | i-zaZswmJk-athena-us-east-2-cell-1-silo-2-00000216.amazonaws.com | host_manager | JDK_8 | events | 11/12/2021 12:38 | 23 | SUCCESS_WITH_RESULT | 53.3 | 138 | 99 | |||||||||||||||||||||
us-east-2 | us-east-2-cell-1 | us-east-2-cell-1-silo-2 | us-east-2-1 | athena | i-zaZswmJk-athena-us-east-2-cell-1-silo-2-00000216.amazonaws.com | host_manager | JDK_8 | events | 11/12/2021 12:36 | 39.4 | SUCCESS_WITH_NO_RESULT | 79.6 | 254 | 82.9 |
Single-measure records
Timestream for LiveAnalytics also allows you to ingest the data with one measure per time series record. Below are the schema details when ingested using single measure records.
Table Schema
Below is the table schema once the data is ingested using multi-measure records. It is the output of DESCRIBE query. Assuming the data is ingested into a database raw_data and table devops, below is the query.
DESCRIBE "raw_data"."devops_single"
Column | Type | Timestream for LiveAnalytics attribute type |
---|---|---|
availability_zone | varchar | DIMENSION |
microservice_name | varchar | DIMENSION |
instance_name | varchar | DIMENSION |
process_name | varchar | DIMENSION |
os_version | varchar | DIMENSION |
jdk_version | varchar | DIMENSION |
cell | varchar | DIMENSION |
region | varchar | DIMENSION |
silo | varchar | DIMENSION |
instance_type | varchar | DIMENSION |
measure_name | varchar | MEASURE_NAME |
time | timestamp | TIMESTAMP |
measure_value::double | double | MEASURE_VALUE |
measure_value::bigint | bigint | MEASURE_VALUE |
measure_value::varchar | varchar | MEASURE_VALUE |
Measure Schema
Below is the measure schema returned by the SHOW MEASURES query.
SHOW MEASURES FROM "raw_data"."devops_single"
measure_name | data_type | Dimensions |
---|---|---|
cpu_hi | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
cpu_idle | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
cpu_iowait | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
cpu_nice | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
cpu_si | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
cpu_steal | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
cpu_system | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
cpu_user | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
disk_free | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
disk_io_reads | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
disk_io_writes | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
disk_used | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
file_descriptors_in_use | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
gc_pause | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'process_name', 'data_type': 'varchar'}, {'dimension_name': 'jdk_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}] |
gc_reclaimed | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'process_name', 'data_type': 'varchar'}, {'dimension_name': 'jdk_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}] |
latency_per_read | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
latency_per_write | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
memory_cached | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
memory_free | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'process_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'jdk_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
memory_used | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
network_bytes_in | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
network_bytes_out | double | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'os_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}, {'dimension_name': 'instance_type', 'data_type': 'varchar'}] |
task_completed | bigint | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'process_name', 'data_type': 'varchar'}, {'dimension_name': 'jdk_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}] |
task_end_state | varchar | [{'dimension_name': 'availability_zone', 'data_type': 'varchar'}, {'dimension_name': 'microservice_name', 'data_type': 'varchar'}, {'dimension_name': 'instance_name', 'data_type': 'varchar'}, {'dimension_name': 'process_name', 'data_type': 'varchar'}, {'dimension_name': 'jdk_version', 'data_type': 'varchar'}, {'dimension_name': 'cell', 'data_type': 'varchar'}, {'dimension_name': 'region', 'data_type': 'varchar'}, {'dimension_name': 'silo', 'data_type': 'varchar'}] |
Example Data
availability_zone | microservice_name | instance_name | process_name | os_version | jdk_version | Cell | region | Silo | instance_type | measure_name | Time | measure_value::double | measure_value::bigint | measure_value::varchar |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | cpu_hi | 34:57.2 | 0.87169 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | cpu_idle | 34:57.2 | 3.46266 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | cpu_iowait | 34:57.2 | 0.10226 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | cpu_nice | 34:57.2 | 0.63013 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | cpu_si | 34:57.2 | 0.16441 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | cpu_steal | 34:57.2 | 0.10729 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | cpu_system | 34:57.2 | 0.45709 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | cpu_user | 34:57.2 | 94.20448 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | disk_free | 34:57.2 | 72.51895 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | disk_io_reads | 34:57.2 | 81.73383 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | disk_io_writes | 34:57.2 | 77.11665 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | disk_used | 34:57.2 | 89.42235 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | file_descriptors_in_use | 34:57.2 | 30.08254 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | server | JDK_8 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | gc_pause | 34:57.2 | 60.28679 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | server | JDK_8 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | gc_reclaimed | 34:57.2 | 75.28839 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | latency_per_read | 34:57.2 | 8.07605 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | latency_per_write | 34:57.2 | 58.11223 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | memory_cached | 34:57.2 | 87.56481 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | server | JDK_8 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | memory_free | 34:57.2 | 18.95768 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | memory_free | 34:57.2 | 97.20523 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | memory_used | 34:57.2 | 12.37723 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | network_bytes_in | 34:57.2 | 31.02065 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | AL2012 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | r5.4xlarge | network_bytes_out | 34:57.2 | 0.51424 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | server | JDK_8 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | task_completed | 34:57.2 | 69 | ||||
eu-west-1-1 | hercules | i-zaZswmJk-hercules-eu-west-1-cell-9-silo-2-00000027.amazonaws.com | server | JDK_8 | eu-west-1-cell-9 | eu-west-1 | eu-west-1-cell-9-silo-2 | task_end_state | 34:57.2 | SUCCESS_WITH_RESULT |
